◆材质：铝合金型材

◆规格尺寸：W*H尺寸可依据设计制造

◆特性：

1.叶片为固定式,叶片倾斜24度，最长为3米，超过时可采用拼接方式。

2.突出了线型设计的特点，可用于室内和大厅环形分布的出风口和回风口。

表面处理：静电喷塑

外框边宽尺寸E有3种：16mm,23mm,32mm

当E=16时，h=42，面尺寸=颈尺寸+20

当E=23时，h=40，面尺寸=颈尺寸+37

当E=32时，h=50，面尺寸=颈尺寸+54

◆Material: aluminum alloy profile

◆Size: W*H size can be designed and manufactured

◆Characteristic:

1. The blade is fixed, the blade is inclined by 24 degrees, and the longest is 3 meters. When it is over, it can be spliced.

2. Highlights the characteristics of the line design, which can be used for the air outlet and return air outlet of the indoor and the hall.

Surface treatment: electrostatic spray
