◆材质：铝板，镀锌板

◆规格尺寸：φ100、φ125、φ160、φ200、φ250、φ315、φ400、φ500、φ630

◆特性：

1.主要用于机场，会展中心，音乐厅，体育馆等高等次的大空间建筑中。

2.送风喷嘴为球型，卡在外壳中，配有铝制装饰圈和可直接为圆插接的圆形接管，喷嘴可在＋/－30℃范围内人工或电动调节。

3.喷嘴为中空双层结构，外层为球形，内层采用最佳空气动力学原理设计，具有射程远，噪音和阻力小，射程诱导比高，室内空气混合性好，工作区域温度均匀，以及在高温地区避免风口表面洁露等特点。

表面处理：静电喷塑

◆Material: aluminum plate, galvanized sheet

◆Specification size: φ100, φ125, φ160, φ200, φ250, φ315, φ400, φ500, φ630

◆Characteristic:

1. Mainly used in airports, convention centers, concert halls, stadiums and other high-rise buildings.

2. The air supply nozzle is spherical and stuck in the outer casing. It is equipped with an aluminum decorative ring and a circular socket that can be directly inserted into the circle. The nozzle can be manually or electrically adjusted within +/-30 °C.

3. The nozzle has a hollow double-layer structure, the outer layer is spherical, and the inner layer is designed by the best aerodynamic principle. It has a long range, low noise and resistance, high range induction ratio, good indoor air mixing, and uniform temperature in the working area. And to avoid the surface of the tuyere in high temperature areas.

Surface treatment: electrostatic spray
