◆材质：铝板

◆规格尺寸：φ250、φ315、φ400、φ500、φ630

◆特性：

1.一般用于层高在3.8米以上的较大的空间，如机场，车站候车厅，会展中心，剧院，体育馆，工业厂房等。

2.风口正面装有可调式叶片和散流圈，叶片根据流体动力学原理设计的，可以使气流形成具有一定初速涡旋流送出，从而使送风射程远，射流覆盖面大，增加气流的对流效果。

3.叶片可根据送风工况的不同而改变送风射角，叶片的调整可以通过人工或电动来完成。

表面处理：静电喷塑

◆Material: aluminum plate

◆Specification size: φ250, φ315, φ400, φ500, φ630

◆Characteristic:

1. Generally used for large spaces with a height of 3.8 meters or more, such as airports, station waiting halls, convention centers, theaters, stadiums, industrial plants, etc.

2. The front side of the tuyere is equipped with adjustable blades and spar grooves. The blade is designed according to the fluid dynamics principle, so that the airflow can be formed with a certain initial velocity vortex flow, so that the air supply range is far, the jet coverage is large, and the airflow convection is increased. effect.

3. The blade can change the air supply angle according to the different air supply conditions. The adjustment of the blade can be done manually or by electric.

Surface treatment: electrostatic spray
