◆材质：铝合金型材

◆规格尺寸：W*H尺寸可依据设计制造

◆特性：

1.叶片在0-180°范围内任意调节，将叶片调节成不同角度，可以得到不同的送风距离和不同的扩散角度，可作回风口使用。

2.由两组活动叶片交错组合而成。

表面处理：静电喷塑

外框边宽尺寸E有3种：16mm,23mm,32mm

当E=16时，h=42，面尺寸=颈尺寸+20

当E=23时，h=40，面尺寸=颈尺寸+37

当E=32时，h=50，面尺寸=颈尺寸+54

◆Material: aluminum alloy profile

◆Size: W*H size can be designed and manufactured

◆Characteristic:

1. The blade can be adjusted arbitrarily within the range of 0-180°, and the blade can be adjusted to different angles to obtain different air supply distances and different diffusion angles, which can be used as a return air outlet.

2. Interlaced by two sets of moving blades.

Surface treatment: electrostatic spray
